SHN-IPS-BHD-W Shinho Vietnam
The SHN-IPS-BHD-W Shinho Vietnam device is one of the advanced models in the automatic fire alarm product line of the Shinho brand – a prestigious unit from China, now available in the Vietnamese market. This device integrates smart sensor functions, modern design, suitable for many different installation environments such as high-rise buildings, factories, warehouses, hospitals, schools, …
Specifications
| Product Name | SHN-IPS-BHD-W Shinho Vietnam |
|---|---|
| Detector type | Wireless fixed heat detector |
| Warning temperature | 70 ± 5°C |
| Operating frequency | 470MHz |
| Power supply | 3V Lithium battery (replaceable) |
| Battery life | About 5 years (depending on frequency of use) |
| Transmission distance | ≤ 150 meters (in unobstructed environment) |
| LED display | Yes (status and warning indication) |
| How to install | ceiling mounted |
| Applicable standards | GB4716-2005 / EN54 equivalent |
| Ambient temperature | -10°C ~ +50°C |
| Environmental humidity | ≤ 95% RH (non-condensing) |
Advantage
-
No need for complicated wiring : Thanks to the wireless connection, SHN-IPS-BHD-W saves installation time and costs, especially suitable for renovation projects or projects with difficult architecture.
-
Fast and accurate response : Fixed temperature sensor operates stably, high precision, helps to promptly detect abnormal temperature increase due to fire.
-
Integrated addressable fire alarm system : Allows accurate location of fire in the system, supporting quick rescue and incident handling.
-
Compact, aesthetic design : Modern design, easy to install in many different spaces without affecting the interior design.
-
Long-life battery : The system uses a battery with a life of up to 5 years, easily replaced when necessary.
Application
-
Factories, production plants : Quickly detect abnormal heat points from machinery or production lines.
-
Shopping malls, supermarkets : Protect the safety of customers and property in crowded areas.
-
Office buildings, high-rise apartments : Convenient installation, enhancing warning and evacuation efficiency.
-
Warehouses, cold storage : Timely fire detection in areas prone to explosion or containing valuable materials.
-
Schools, hospitals : Ensure safety for public areas with high population density.
